Xterra U15 User Manual

21
PARTS LIST
Item
Front Main Frame
Usage
1
Main Frame
1
2
Console Mast
1
3
Seat Carriage Assembly
1
4
Sliding Seat Mount
1
5
Front Stabilizer
1
6
Rear Stabilizer
1
7
Idler Wheel Assembly
1
8
Drive Pully
1
9
Handle Bar
1
10
Crank Arm - L
1
11
Crank Arm - R
1
12
Bearing φ35*17*10mml
2
13
Slider Sleeve
1
14
Bearing
1
15
Pull Pin
1
16
HandleBar Adj. Knob
1
17
Seat Adj. Knob
1
18
Seat Carriage End Cap
2
19
Button Head Plug
2
20
O-ring 40*80mm
2
21
Grommet
1
22
Shroud - L
1
23
Shroud - R
1
24
Console Mast Cover
1
25
Hand Grip Foam
2
26
Spring
1
27
Carriage Bolt M10*35mml
1
28
Carriage Bolt M8*72mml
4
29
Button Head Socket Screw M10*35mml
1
30
Button Head Socket Screw M10*20mml
1
31
Button Head Socket Screw M8*15mml
6
32
Phillips Head Screw M5*12mm
2
33
Tapping Screw φ5*16mm
9
34
Bolt 3.5*20mm
8
35
Washer φ17.2*22*2t
2
36
Washer φ17.2*22*0.5t
2
37
Flat Washer φ10*30*3t
1
38
Flat Washer φ10*20*3t
3
39
Flat Washer φ10*20*1.5t
4
40
Flat Washer φ8*16*1.5t
4
41
Flat Washer φ8*21*2t
4
42
Cup Washer φ8*21*2t
2
43
Block φ10*15*11mm
1
44
Block φ8*13*6mm
1
45
Hexagon Nut 3/8"*9t
2
46
Nut M10*9mm
2
47
Hexagon Nut M10*1.25
2
48
Circlip φ17*1t
1
