Xterra UB1.7 User Manual

UB1.7 Upright Bike
3
#33. Combination M5 Allen Wrench
& Phillips Head Screw Driver
#74. 3/8”
Flat Washer
(1 pc)
#31. M5 x 12mm
Phillips Head Screw
(4 pcs)
#15. M8 x 30mm
Button Head Socket
Bolt (1 pc)
#73. 3/8” x 1-1/2”
Carriage Bolt
(1 pc)
UB1.7 Assembly Pack Checklist
Hardware Step 1
#27. 5/16”
Flat Washer
(8 pcs)
#26. 5/16” x 3/4”
Button Head Socket
Bolt (9 pcs)
Hardware Step 2
#64. 13/15mm Wrench
Assembly Tools
#28. 5/16”
Curved Washer
(1 pc)
#29. 5/16”
Split Washer
(9 pcs)

Xterra UB1.7 Specifications

General

Brand	Xterra
Model	UB1.7
Category	Exercise Bike
Language	English
