Page 38
STEP 31: FRONT SUSPENSION MOUNTING
(148558) Lock Nut 3mm -- 2
(148645) Flat Head Screw w/Threadlock 4 x 10mm -- 2
(148643) Flat Head Screw 3 x 16mm -- 2
(148646) Flat Head Screw 4 x 15mm -- 6
148558
150036
Step 26
148643
148645
148646
Step 30
148646
148646
ExpLODED vIEW ASSEmBLY DRAWINGS
Continued On Next Page
To Next Page
