Page 39
STEP 32: REAR SUSPENSION MOUNTING
(148558) Lock Nut 3mm -- 1
(148643) Flat Head Screw 3 x 16mm -- 1
(148646) Flat Head Screw 4 x 15mm -- 4
149501
148558
Step 17
148646
148646
148646
148643
Step 31
ExpLODED vIEW ASSEmBLY DRAWINGS
Continued On Next Page
