7
12V DC INPUT CUT OUT CUT IN
HIGH 11.1V 12.4V
MEDIUM 10.4V 11.7V
LOW 9.6V 10.9V
24V DC INPUT CUT OUT CUT IN
HIGH 22.9V 23.9V
MEDIUM 22.3V 23.3V
LOW 21.3V 22.7V
BATTERY PROTECTION
SETTING
The fridge is equipped with a multi-level Battery
Protection that protects a battery against excessive
discharging when the fridge is connected to 12V or
24V DC power source such as a vehicle battery.
IMPORTANT: When using the fridge with supplied
AC Adapter, we recommended setting the Battery
Protection to LOW.
1. The fridge will automatically restart once input
voltage is reached and will retain all original
settings prior to monitor being activated.
2. Audible beeping will be heard when monitor is
activated.
