XTM XTM40 - Connection Sockets and Switches

XTM40 Function description
11
Connection sockets
Item in
fig. 4
Description
1 AC voltage supply inlet
2Fuse holder
3 DC voltage supply inlet
4 Emergency switch
100-240V~AC
FUSE
12/24V DC
EMERGENCY OVERRIDE
NORMAL USE
4
1
2 3
4
