Xtracer 1152 - Page 53

© Xtrac 2015 Page 1 of 5

Product:
P1152 Gearbox
Date:
07/07/2015
To:
All 1152 customers
Ref:
1
152
-
00
0
2
From:
Angelo Wilson
Position:
Design Engineer

Technical Bulletin Action Level
Requires Immediate Action
For Information Only
Ref Description
1 1152-407-000A BELLHOUSING
The 1152-407-000A Bellhousing has been up-issued to revision 5 to incorporate the
following design changes:
1) Material has been added around the floor fixings to increase casing strength
(ref. Figure 1.1 & Figure 1.2).
2) The cast logos that previously featured on top of the casing have been
removed (ref. Figure 1.1).

Figure 1.1: Bellhousing Updates
2
2
1
