Xtralis VESDA E-Series User Manual

Commission a System
VESDA Student Workbook 8-5
3) Configuration and thresholds
To configure VESDA panels using VSC:
• Launch VSC software
• Click Connect and View…
• Check the connection
• Click OK
• Double-click the Detector
3) Configuration and thresholds
• Configure the system:
– Zones
– Remote Modules
– Relays
– GPI
– Reference
– Ethernet/ Wi-Fi
• Set:
– Flow Thresholds
– Smoke Thresholds
– Set Aspirator Speed
– Normalize Airflow

Xtralis VESDA E-Series Specifications

General

Brand	Xtralis
Model	VESDA E-Series
Category	Smoke Alarm
Language	English
