Xtralis VESDA E-Series User Manual

Section 4
VESDA Student Workbook 4-1
VESDAnet Connection
VESDAnet technical features
• Max 100 detectors
• Max 200 devices (only 100 detectors max)
• RS485 Interface runs over shielded twisted
pair wire up to 1.3km (4,160 ft) in length (from
node to node)
• Daisy chain loop configuration, half duplex
• VESDAnet is RS-485(15-pin) or USB
• Fault tolerant
• Cabling can run from any port to any port
(recommend A-B-A-B on larger networks)
• Open Loop optional, but not recommended
