Xtralis VESDA E-Series User Manual

VESDA by Xtralis VESDA PipeNetwork Design Guide
www.xtralis.com 31
Legend
A Detector
B Sampling pipe 1
C Sampling pipe 2
D Sampling pipe 3
E Sampling pipe 4
Figure 6-4: Plotting the sampling pipes by connecting the sampling holes and terminating at the detector
