VEA Tubes and
Sample Points
VEA (recommended sample point fittings)
• 40 tubes inlet maximum (addressable)
• 6 tubes minimum
• 328 ft. maximum tube length
• Keep all tubes same length
• Coil up unused tubing
Model Variants:
VEA-A00 LED version
VEA-A10 3.5” display version
