Page #71 background imageLoading...
Page #71 background image
IP Network Structure
FireWorks
(Edwards FW-UL6W)
VESDA Network
Serial to
Ethernet
Converter
(MN-COM1S)
Serial to
Ethernet
Converter
Connection options
VESDAnet
A VESDAnet network allows:
• The VESDA detector to report alarms and
faults to a Fire Panel using a HLI (High Level
Interface)
• Configuration and monitoring of devices from
a central computer
