XTZ Sub Amp 1 - Input and Output Functions; Phase, High Pass, and Balance; Line, Speaker, and AC Inputs

-
10
-
PHASE
0-180 phase adjustment
HIGH PASS
Switch ON and the high pass are available. Switch
OFF and the high pass are unavailable.
The high pass crossover removes the
deepest part of the b
ass spectra. This is
helpful in many rooms, since they heavily
amplify the deep bass tones, which may
lead to uncontrolled bass.
BALANCE
Balanced input
LINE IN
Line-
level inputs to subwoofer. Use these RCA
jacks to connect audio signals from line-
level
outputs on a receiver, preamplifier, television set or
surround sound decoder. If only a mono (single)
subwoofer output is provided, connect it to either
of input jack.
Remark: By connecting both lines
in
inputs to the same signal, you increa
se the
level by 3 dB. Certain types of simpler low
level audio cables may create a noise in
the subwoofer. We recommend double
shielded low level cables to be used.
SPEAKER IN
Stereo high-
level inputs to subwoofer. Use these
terminals when line-level
connections are not
available from receiver, preamplifier or surround
sound decoder.
AC INPUT
Connect to regular 230 V / 50 Hz.
OUT
(SPEAKER OUT)
High Level OUTPUT to speaker/passive subwoofer.
Stereo high-level inputs to subwoofer. Use th
ese
terminals when line-
level connections are not
available from receiver, preamplifier or surround
sound decoder.
