6.6 Winding data
Stator number 13–10–2B
Table 3: 1-phase
Part number Number of stator leads Winding resistance (Ohm)
6389601 4 1.77
3.66
6389603 4 1.34
2.71
Table 4: 3-phase
Part number Number of stator leads Winding resistance (Ohm)
6389501 6 3.06
6389503 6 3.65
6389506 9 1.38
6389508 6 1.99
6389511 6 0.572
6389516 12 4.20
6389517 3 4.69
6389518 3 3.06
6 Technical Reference
2620.172/.281 Service and Repair Instructions 69
