1630 Headstock Parts List
Item
Parts No.
Description
Material
Specification
Q’ty
41
24712
Gear – Oil Pump
UMC1
25-0111
1
42
Socket Head Cap Screw
M6x20L
2
43
Washer - Flat
M6
2
44
Washer - Spring
M6
2
45
24731
Gasket
25-0104
1
46
25-0103
Cover - Headstock
FC20
1
47
Socket Head Cap Screw
M8x25L
6
48
Plug - Oil
PT-3/4
1
49
Socket Head Cap Screw
M16x50L
4
50
Washer - Spring
M16
4
51
Hexagon Head Screw
M12x1.75X20L
2
52
21234-119
Oil Sight Glass
50-01146
HFTX22
1
53
24713
Seal - Oil
TC22x35x6
1
54
24725
Spacer
SS41
77USA-0144
1
