2.12 Cable Interconnections
All cable interconnections are made at the factory except for those connecting to the
pendant display. There are a total of 6 cables that need to be connected to the
pendant. See Figure 6 for pendant cable connections.
With the main 415 volt power to the machine turned off plug in the connectors that
are bundled on the side of the machine. Each cable fits to only one connector on the
pendant display, on the left side of the pendant. Use the key on the pendant to
match up the connectors with the correct port. The machine ID key and option keys
should be plugged into the port labeled as such. The test port and X and Y
handwheel ports will be left empty during installation. If the customers sets this
machine up on a network, this cable will also need to be plugged in.
Make sure the machine ID key is plugged in, otherwise the machine will not run.
Also make sure there is a hardware (option) key plugged into the parallel port of the
pendant. This key activates any converters or options ordered. The key must be
programmed according to the type of machine it is on and the options ordered.
CAUTION!
Make sure the main 415-volt power switch is disconnected on the back of the electrical cabinet
before plugging in the cables.
