XYZ Machine Tools
ProTURN SLX 1630 ProtoTRAK SLX CNC Safety, Installation, Service & Parts List Manual
Figure 3
Lifting SLX 1630
(May not represent
actual machine)
Do not attempt to lift this
machine with a forklift
having less than 2722 kg
capacity for the 1630. The
shipping weight of the
machines including
electronics is 1247 kg.
Place the machine in position
on top of the (4) rest pads
for the SLX 1630.
For proper operation, the
machine should be set on a
substantial floor capable of
supporting the weight safely.
For the location of the bolt
holes, size and
recommended mounting (see
Figures 1 & 2).
