ADDING PLATFORM ELEMENTS
Lay out the platform ele-
ments (K, L, M, N) and align
them with the threaded holes
on the side rails (A, B).
Start with the large head el-
ement (K), followed by the
base (L), leg (M) and foot (N)
element.
NOTICE
While placing the platform elements (K, L, M, N) be careful not to trip over the side to side (I) or
the power cable (H).
Use the 14 mounting screws (O)
to fix all the platform elements by
hand. Screw them in hand tight.
ATTACHING THE USB-MODULES
CONNECTING THE POWER CABLE
Connect the power cable (H) to
the power converter (G) and run
the cable to the nearest power
outlet without tensioning the ca-
ble. Lay the cable behind the bed
and near walls to avoid tripping
over the power cable.
Refer to the grounding instruc-
tions for information about
proper grounding.
NOTICE
Do not put strain on any cables.
G
H
REMOVE ALL RIBBONS BEFORE
MOUNTING THE PLATFORMS !
Bring the two USB-modules (J)
into their final position by clicking
them onto the preinstalled mount-
ing plates under the base element.
2x
J
FOOT
HEAD
