Yadea C1S Service Manual

General Information
10
Right brake disconnect wire
Throttle grip wire
Left turn signal wire
Right turn signal wire
Right combination switch cable
Fix the L/R combination switch and
brake switch to the stay on the handle pipe
Four holes (throttle grip)
Six-hole black (right combination switch)
Left brake disconnect wire
Left combination switch wire
Two holes (right brake handle)
Two holes (left brake handle)
Six-hole white (left combination switch)

Yadea C1S Specifications

General

Battery Type	Lithium-ion
Range	up to 100 km
Brakes	Front and rear disc brakes
Category	Electric Scooter
Max Load	150 kg
Tire Size	12 inches
Charging Time	6 hours
