11 Specifications
12 Troubleshooting
Cleaning & storage
Rub the scooter with a piece of soft, wet cloth. Remove sticky dirt with a tooth brush and toothpaste, and
clean with a piece of soft, wet cloth.
ATTENTION:
Do not clean your scooter with alcohol, gasoline, acetone or other corrosive/volatile solvents, which may
compromise your scooter appearance and internal structure. Do not wash your scooter with forced cleaner.If
the electric scooter is used for a long time, the screws may be loose, which may cause the riser to shake.
Commissioning required
WARNING:
Before cleaning, turn off the power, remove the charging cable, close the rubber cover at the charging port
to prevent damaging the electronic components.
Place your scooter at a shady and dry location. Do not put your scooter outside for a prolonged period.
Direct sunlight and extreme temperatures (cold and hot) may accelerate the ageing of plastic parts and
compromise the battery life.
Prolonged Exposure to UV Rays and the Elements May Damage the Enclosure Materials,Store Indoors
When Not in Use.
13 Maintenance and repairs
* Typical range: measured when the scooter is fully charged, with a load of 75kg, ambient temperature of
22℃, no wind, flat asphalt road surface, and at a constant speed of 15km/h.�
Tips：For any queries, contact customer service center at www.yadea.com or via afterservice03@yadea.com.cn
Code Error Indication Solution
E0 Communication error
Check wiring between controller,instrument and battery,
replace controller, instrument or battery when necessary
E1 Handlebar error Check wiring or replace handlebar
E2 Braking error Check wiring or replace braking shut-off switch
E3 Motor Hall error Check Hall wiring or replace motor
E4 Motor phase wire or MOS tube short circuit error Check motor phase wire or replace motor/controller
E5 Controller error Check controller wiring or replace controller
E6 Battery error Check battery connection or replace battery
15 16
Parts
Wheel
Motor
Battery
Charger
Machine
Features
Items
Front Wheel
Rear Wheel
Nominal Power
Max Torque
IP Rating
Rating Voltage
Working Voltage
Capacity
Charging Temperature
Protection Functions
Overcharging/Over-discharging/Short circuit/
Over heating and over current protection
Input Voltage
Input Current
Output Voltage
Output Current
Charge Time
Charger Model
Max Speed
Typical Range
Braking System
Max Slope
Weight Limit
Net Weight
Riding Modes
Parameters
10 Inch
10 Inch
500W
≥35N·m
IP65
36V
30 - 42V
15.3Ah
0-45℃（32 - 113°F）
AC100-240V
≤2.5A
42V
1.7A
≈8h
NBW41D001D7D
eKFV: 20km/h, EN17128: 25km/h, UL: 30km/h
50km(31mile)
Front Drum Brake + Rear Disc Brake + Electric Brake
18%
110kg（242lbs）
21.6kg
Pedestrian, Drive and Sports
Energy recovery, lock and unlock your scooter
via the App
Others
