Yaesu FRG-7 Digital User Manual

21
Aer seng the oset, the mode is now also visible in the display.
Picture 35 : AM mode Picture 36 : USB mode
3.5 Offset removal of AM, LSB and USB
Somemes it can be necessary to remove all the oset values, stored in EEPROM.
The next procedure will make them all zero again. Also the mode indicaon on the display will
disappear, because no LSB or USB oset has been programmed.
The brightness seng of the screen and the calibraon value will remain in EEPROM.
To make these values zero, the following procedure should be followed carefully.
• Switch o the FRG-7
• Place jumper J6 and J7
• Switch on the FRG-7
• Aer startup the following screen will appear
Picture 37 : Reset oset
• Aer 4 seconds this text will disappear and jumper 6 must be removed
• Next jumper 7 must be removed
Now the oset values are set to zero and stored in EEPROM.

Yaesu FRG-7 Digital Specifications

General

Brand	Yaesu
Model	FRG-7 Digital
Category	Receiver
Language	English
