Yaesu FT-65R User Manual

The direction of the scan may not reverse while FT-65R/E
is scanning.
For more details on the scanning, see page 35.
Transmission
•
To transmit, press the PTT switch, and speak into the front panel micro-
phone (located in the lower left-hand corner of the speaker grille) in a nor-
mal voice level. The TX/BUSY indicator will glow red during transmission.
•
To return to the receive mode, release the PTT switch.
•
During transmit, the power level will be indicated relatively on the bar
graph at the bottom of the LCD. Full scale deection conrms “High Pow
-
er” operation. Five bars indicate “Medium Power” operation, while one bar
indicates “Low Power” operation. Additionally, while operating on the “Low
Power” or “Medium Power” setting, the “
” icon or “ ” icon will appear
at the bottom-left of the display.
Changing the Transmit Power Level
To change the power level:
1. Press the F key and then press the [P2] key.
• The present TX power output level will appear on the display.
• To adjust the TX power in the Set Mode, press and hold the F key.
Then repeatedly press the [▲] or [▼] key to select Set Mode item “32 TX
PWR” and then press the F key.
2. Press the [▲] or [▼] key to select the desired power output level.
Available selections are “HI ” (5 W), “MID” (2.5 W), and “LOW” (0.5 W).
3. Press the PTT switch to save the new setting and return to normal oper-
ation.
21
Basic Operation
FT-65R/FT-65E Operating Manual

Yaesu FT-65R Specifications

General

Power Output	5W / 2.5W / 0.5W
Antenna Connector	SMA Female
Channel Steps	5, 6.25, 10, 12.5, 15, 20, 25, 50 kHz
Supply Voltage	7.4V DC
IP Rating	IP54
Operating Modes	FM
Battery	7.4V, 1950mAh Li-Ion Battery
Channels	200
