14
Battery Installation and Removal
To install the battery, insert the battery pack
SBR-
39LI
into the battery compartment on the back of the
transceiver
, press the end of the battery pack while
pressing the battery pack latch on the bottom of the
transceiver
, then lock the pack by sliding the locking
plate beside the latch until the entire
“LOCK” ap-
pears
.
Note:
Be sure that the rubber gasket on the
SBR-39LI
is
not loose when inserting.
To remove the battery, turn the
transceiver
o, slide
the locking plate until the
“UNLOCK” appears
en-
tirely
, lift up the
end of the battery pack by pressing
the battery pack latch, then pull out the battery from
the radio.
PUSH
DATA
MIC/SP
EXT
DC
Battery Pack
Latch
Do not attempt to open any of the recharge-
able Lithium-ion packs, as personal injury
or damage to the Lithium-ion pack could
occur if a cell or cells become accidentally short-
circuited.
Note:
To remove the battery pack after the belt clip
SHB-11
is mounted (see Page 15), lift up the clip before you
press the battery pack latch.
Caution:
Risk of explosion if battery is replaced by an incorrect
typ.
Dispose of used batteries according to the instructions.
