IF Unit

6B-6

Parts List

REF. DESCRIPTION VALUE V/W TOL. MFR’S DESIG VXSTD P/N VERS. LOT.

LAY ADR

C 2074 CHIP CAP. 0.047uF 50V F GRM40F473Z50PT K22171008 1-

C 2075 CHIP CAP. 0.047uF 50V F GRM40F473Z50PT K22171008 1-

C 2076 CHIP CAP. 0.047uF 50V F GRM40F473Z50PT K22171008 1-

C 2077 CHIP CAP. 0.047uF 50V F GRM40F473Z50PT K22171008 1-

C 2078 CHIP CAP. 0.047uF 50V F GRM40F473Z50PT K22171008 1-

C 2079 CHIP CAP. 0.047uF 50V F GRM40F473Z50PT K22171008 1-

C 2080 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 2081 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 2082 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 2083 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 2084 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 2085 CHIP CAP. 10pF 50V CH GRM40CH100D50PT K22170211 1-

C 2086 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 2087 CHIP CAP. 0.047uF 50V F GRM40F473Z50PT K22171008 1-

C 2088 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 2089 CHIP CAP. 0.047uF 50V F GRM40F473Z50PT K22171008 1-

C 2090 CHIP CAP. 0.047uF 50V F GRM40F473Z50PT K22171008 1-

C 2091 CHIP CAP. 0.047uF 50V F GRM40F473Z50PT K22171008 1-

C 2092 CHIP CAP. 0.047uF 50V F GRM40F473Z50PT K22171008 1-

C 2093 CHIP CAP. 0.047uF 50V F GRM40F473Z50PT K22171008 1-

C 2094 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 2095 CHIP CAP. 470pF 50V CH GRM40CH471J50PT K22170251 1-

C 2096 CHIP CAP. 470pF 50V CH GRM40CH471J50PT K22170251 1-

C 2097 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 2098 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 2099 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 2100 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 2101 CHIP CAP. 10pF 50V CH GRM40CH100D50PT K22170211 1-

C 2102 CHIP CAP. 0.047uF 50V F GRM40F473Z50PT K22171008 1-

C 2103 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 2105 CHIP CAP. 0.047uF 50V F GRM40F473Z50PT K22171008 1-

C 2106 CHIP CAP. 0.047uF 50V F GRM40F473Z50PT K22171008 1-

C 2107 CHIP CAP. 0.047uF 50V F GRM40F473Z50PT K22171008 1-

C 2108 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 2109 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 2110 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 2111 CHIP CAP. 0.047uF 50V F GRM40F473Z50PT K22171008 1-

C 2112 CHIP CAP. 0.047uF 50V F GRM40F473Z50PT K22171008 1-

C 2114 CHIP CAP. 0.047uF 50V F GRM40F473Z50PT K22171008 1-

C 2115 CHIP CAP. 0.047uF 50V F GRM40F473Z50PT K22171008 1-

C 2116 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 2117 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 2118 CHIP CAP. 0.047uF 50V F GRM40F473Z50PT K22171008 1-

C 2119 CHIP CAP. 0.047uF 50V F GRM40F473Z50PT K22171008 1-

C 2120 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 2121 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 2122 CHIP CAP. 10pF 50V CH GRM40CH100D50PT K22170211 1-

C 2124 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 2125 CHIP CAP. 0.047uF 50V F GRM40F473Z50PT K22171008 1-

C 2126 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 2127 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 2129 CHIP CAP. 27pF 50V CH GRM40CH270J50PT K22170221 1-

C 2130 CHIP CAP. 0.047uF 50V F GRM40F473Z50PT K22171008 1-

C 2131 CHIP CAP. 0.001uF 50V B GRM40B102M50PT K22170805 1-

C 2133 CHIP CAP. 0.047uF 50V F GRM40F473Z50PT K22171008 1-

C 2134 CHIP CAP. 0.001uF 50V B GRM40B102M50PT K22170805 1-

C 2135 CHIP CAP. 0.01uF 50V F GRM40F103Z50PT K22171004 1-

C 2136 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 2137 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 2138 CHIP CAP. 1pF 50V CK GRM40CK010C50PT K22170202 1-

C 2139 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 2140 CHIP CAP. 10pF 50V CH GRM40CH100D50PT K22170211 1-

C 2141 CHIP CAP. 0.047uF 50V F GRM40F473Z50PT K22171008 1-

C 2142 CHIP CAP. 0.047uF 50V F GRM40F473Z50PT K22171008 1-

C 2143 CHIP CAP. 0.047uF 50V F GRM40F473Z50PT K22171008 1-

C 2144 CHIP CAP. 0.047uF 50V F GRM40F473Z50PT K22171008 1-

C 2145 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

C 2146 CHIP CAP. 0.01uF 50V B GRM40B103M50PT K22170817 1-

Frequency Range RX	100 kHz - 30 MHz
Receiver Type	Double conversion superheterodyne
Antenna Impedance	50 ohms
Weight	15 kg
Voltage	13.8 VDC
Modes	AM, FM, SSB, CW, FSK
Current Drain TX	22 A
Receiver Sensitivity	0.16 μV (SSB, CW)
Frequency Range TX	160, 80, 40, 30, 20, 17, 15, 12, 10 m

Yaesu Mark-V FT-1000MP Field User Manual
