HighTh
(High Threshold)
This parameter can be used to set the input-signal level at which the
compressor starts to process the sound in the high-frequency band.
Settings: -54dB to -6dB
HighAtk
(High Attack)
This parameter can be used to set the amount of time that elapses between
arrival of an input signal and activation of the compressor in the high-
frequency band.
Settings: 1ms to 200ms
HighRat
(High Ratio)
This parameter can be used to set the compression ratio for the high-
frequency band.
Settings: 1.0 to 20.0
HighGain
(High Gain)
This parameter can be used to set the output level for the high-frequency
band.
Settings: -∞ to +18dB
DivFreqL
(Low Dividing
Frequency)
This parameter can be used to set the frequency that divides the low- and
mid-frequency bands.
Settings: 16Hz to 20kHz
DivFreqH
(High Dividing
Frequency)
This parameter can be used to set the frequency that divides the mid- and
high-frequency bands.
Settings: 16Hz to 20kHz
CmnRel
(Common Release)
Affecting all three compression bands, this parameter can be used to set
the amount of time that elapses until the sound is no longer being
compressed.
Settings: 10ms to 3000ms
Parameter name Description
