1034839B-2/18
If your vehicle has a fairing, you must
remove it if there is any interference.
Open levers all the way
to lower clamps.
Place box on vehicle with
clamps in front of crossbars.
A friend could help with this.
Loosen track thumb wheel 1/2 turn.
Do not remove wheel.
INSIDE THE BOX:
LOAD CARGO BOX ONTO VEHICLE:
REMOVING THUMBWHEELS WILL
CAUSE DISASSEMBLY OF LEVER/
CLAMP MECHANISM.
Lid will open both ways for ease
of installation.
• Latches must be engaged before
opening other side.
• Box should only be opened one
side at a time.
OPEN GEAR BOX.
• Insert key. Turn counter clock-wise to unlock.
• Rotate handle (handle will not rotate if box is locked).
• Lift to open.
To Next Page
