Yakima SpaceCadet - Installation Guide; Opening the Cargo Box; Preparing the Clamps; Loading onto Vehicle

1033332A-2/15
Open levers all the way to
lower clamps.
Place box on vehicle with
clamps in front of crossbars.
A friend could help with this.
Loosen track thumb wheel 1/2 turn.
Do not remove wheel.
INSIDE THE BOX:
LOAD CARGO BOX ONTO VEHICLE:
REMOVING THUMBWHEELS
WILL CAUSE DISASSEMBLY OF
LEVER/CLAMP MECHANISM.
OPEN THE BOX
(Use the key to unlock
the box).
• TO OPEN THE BOX, unlock it.
• With the key still inserted,
raise the lid.
The key cannot be removed
while the box is open.
BARS THAT MOVE:
TIGHTEN YOUR CROSSBARS IF
YOU LOOSENED THEM.
If your vehicle has a fairing, remove the fairing prior to box installation.
Q TOWERS:
NEVER REPOSITION
THE TOWERS!
CROSSBAR SPREAD
RocketBox .........................30" - 36" (76 - 91 cm)
SpaceBooster ...................30" - 36" (76 - 91 cm)
SpaceCadet .......................24" - 36" (61 - 91 cm)
