Yale 3000 Series User Manual

80-9303-2207-010 Rev 2 (09-17)
An ASSA ABLOY Group brand
CLOSED
70°
10°
(Use 5/16” socket or adjustable wrench for this adjustment)
Spring Power Adjust
Backcheck
Sweep
Latch
(Use 1/8" Hex Wrench for these Adjustments)
Closer is shipped set at mid range setting = 10 turns
Adjustment Chart
EXTERIOR
INTERIOR
Regular Arm
Top Jamb
Regular Arm
Top Jamb
Parallel Arm
Parallel Arm
FULL 360° TURNS OF
5/16 POWER
ADJUSTMENT WRENCH
3110/3310/3510
DOOR
TYPE
OF
INST.
*
32”
(0.85M)
36”
(0.90M)
42”
(1.00M)
48”
(1.20M)
5
8
11
13
7
10
13
16
7
10
13
16
9
12
16
18
20 FULL (360°) TURNS MAXIMUM AVAILABLE
*
MAXIMUM DOOR SIZE
Number of Turns Required
To Set Hold Open
Use 1" Wrench
Open Door to Desired Angle
To identify your model:
Closer Size
Mfg.
Date
1F
A
3
Blank = 3311/3511
2 = 3312/3512
3 = 3313/3513
4 = 3314/3514
5 = 3315/3515
6 = 3316/3516
6
Product Support Tel 800.438.1951 • www.yalecommercial.com
Yale® is a registered trademark of Yale Security Inc., an ASSA ABLOY Group company. Copyright © , 201 , Yale Security Inc., an ASSA ABLOY Group company. All rights reserved. 2004 7
Reproduction in whole or in part without the express written permission of Yale Security Inc., an ASSA ABLOY Group company is prohibited.

Yale 3000 Series Specifications

General

Keypad	Yes
Backlit Keypad	Yes
One-Touch Locking	Yes
Low Battery Indicator	Yes
Handing	Reversible
Door Thickness	1-3/8" to 1-3/4"
Deadbolt Throw	1"
Auto-Lock	Yes
Battery	4 AA
Finish	Satin Nickel
Backset	2-3/8" or 2-3/4"
ANSI Grade	2
