Yale Assure Lock Lever Push Button YRL216 User Manual

P/N YRL-LPBINSTL-FUL Rev D
2
Preparing to Install
Utility Knife
Drill
Wood Mortise
Chisel
Pencil
Tape
Measure
Level
Tools necessary only for new
doors or adjusting existing prep.
Template
Tools Needed
Standard
Phillips Head
Screwdriver
2-3/8" through bolt posts
2-3/4" through bolt posts
Note: Adjustment based on
backset
O
optional
default
PULL
*Backset
*2-3/8" (60mm) or 2-3/4" (70mm)
