Yale Assure Lock Lever Push Button YRL216 User Manual

P/N YRL-LPBINSTL-FUL Rev D
4
?
Determining Door Handing
Left Hand Right Hand
Face a door swinging open
away from you.
If it swings open to the right,
it is a right hand door. If it
swings open to the left, it is a
left hand door.
Exterior
Inswinging Door
Interior
Left Hand
Reverse
Right Hand
Reverse
Face a door swinging open
toward you.
If it swings open to the right, it
is a right hand reverse door. If it
swings opens to the left, it is a
left hand reverse door.
Exterior
Outswinging Door
Interior
Curve of latchbolt must contact strike plate first.
Frame
Door
Latchbolt Curve
Strike
Plate
Exterior
Interior
Outside of Door

Yale Assure Lock Lever Push Button YRL216 Specifications

General

Brand	Yale
Model	Assure Lock Lever Push Button YRL216
Category	Locks
Language	English
