Yale Assure Lock Lever Push Button YRL216 User Manual

P/N YRL-LPBINSTL-FUL Rev D
7
2
Outside of
Right Hand Door
Inside of
Right Hand Door
Installing Push Button
Right Hand Installation Shown
!
!
“TOP” mark must be
on top surface and tailpiece
in vertical position.
Incorrect orientation will
cause lock to fail.

Yale Assure Lock Lever Push Button YRL216 Specifications

General

Brand	Yale
Model	Assure Lock Lever Push Button YRL216
Category	Locks
Language	English
