2
P/N YRL-EMICL-256-KFTSINSTL-FUL Rev A
Before You Begin
1-3/8" (35mm) Min to
1-3/4" (44.5mm) Max
4-1/2"
(114)
Min
x1
x2
x8
x2
x2
Smart Module
(Optional)
3/32"
1/8"
#2
1/8" 2-1/8"
1
1"
x2 Black
M6x44mm
PPHMS
(Standard 1-3/4" - 2")
OR
x2 Gold
M6x36mm
PPHMS
(1-3/8")
Template
Door Thickness
FOLD HERE
Door Edge
Recommended Centerline
36" (91 cm) From Floor.
Backset
5/32"
(3.96mm)
Caution: Copy machines
may change the size of the
template and make it
inaccurate.
263006837 (01-16)
1" (25mm)1" (25mm)
2-1/8" (54mm)
2-1/8" (54mm)
2-3/4" (70mm)
2-3/8" (60mm)
4" (101mm)
5-1/2" (139.7mm)
1" (25mm)
2-1/8" (54mm)
"Backset" is the distance
from the door edge to the
center of the mounting
hole for the lever.
1-3/8"
(35mm)
1-3/4"
(45mm)
Caution: Although a door
can be prepared by an
untrained person, Yale
recommends that
measurements and drilling
be done by a skilled
carpenter or locksmith.
Yale® is a registered trademark of Yale
Security Inc., an ASSA ABLOY Group
company. Copyright © 2016, Yale
Security Inc., an ASSA ABLOY Group
company.
All rights reserved. Reproduction in
whole or in part without the express
written permission of Yale Security Inc.
is prohibited.
www.yalelocks.com
1-800-438-1951
Interconnected
Lockset
An ASSA ABLOY Group brand
2-3/8" (60mm)
To Next Page
