9
P/N YRL-EMICL-256-KFTSINSTL-FUL Rev A
Lockset Handing Configurations
4" Left Hand
For 5.5"
For 4"
4" Right Hand
For 5.5"
For 4"
After handing is changed, check that lever and thumbturn rotate freely.
Test Lever and Thumbturn
!
Confirm RH is
visible thru RH hole
as shown for
right hand installation.
!
Confirm LH is
visible thru LH hole
as shown for
left hand installation.
