7
P/N YRL-EMICL-256-KFTSINSTL-FUL Rev A
3
Changing Handing (if necessary)
4-24 x 1/4" PPHMS
4" Left Hand to 4" Right Hand Shown
x2
3
!
DO NOT TAMPER
WITH OR LOOSEN
E-CLIP AND ITS
ASSEMBLY
!
DO NOT LOOSEN
THESE 6 SCREWS
OR REMOVE
COVER
