Yale AYRD110

3
P/N -110- - - Rev DAYRD STANDALONE INST FUL
O
x4
1
d faute
2-3/8" position
2-3/4" position
Installing Latch & Strike Plate
Press
Pull
optional
Bolt must be in retracted
(unlocked) position. Note
horizontal orientation of
mechanism.
