Yale GLP90VX Service Manual

Legend for Figure 7
NOTE: SEE TABLE 1 FOR HOLES TO USE TO ATTACH ROD END OF GAS SPRING.
A. GLC40, 45, 55VX; GLC55SVX; (GC/GLC080,
100, 120VX; GC/GLC080, 100VXBCS; GC/
GLC120SVX; GC/GLC120VXPRS) (E818, F818)
B. GLP/GDP40VX5/VX6; GLP/GDP45SVX5, GLP/
GDP45VX6; GLP/GDP50-55VX (GP/GLP/
GDP080, 090, 100, 110, 120VX) (F813, G813,
H813, J813)
C. LEFT SIDE
D. RIGHT SIDE
1. MOUNTING LOCATION FOR CYLINDER END OF GAS SPRING FOR NON-SUSPENSION SEAT
2. MOUNTING LOCATION FOR CYLINDER END OF GAS SPRING FOR SEMI OR FULL SUSPENSION SEAT
Table 1. Gas Spring Installation, Holes for Installing Rod Ends (See Figure 7)
Counterweight
Type
Full or Semi Suspension Seat Non-Suspension Seat
Left Side Right Side Left Side Right Side
Standard
Counterweight
GLC40, 45, 50, 55VX
(GC/GLC080, 100,
120VX) (E818, F818)
3 3 1 1
Standard
Counterweight GLP/
GDP40VX5/VX6;
GLP/GDP45SVX5,
GLP/GDP45VX6;
GLP/GDP50-55VX
(GP/GLP/GDP080,
090, 100, 110,
120VX) (F813, G813,
H813, J813)
2 2 1 1
BCS and PRS
Counterweights
GLC55SVX (GC/
GLC080,
100VXBCS, GC/
GLC120SVX; GC/
GLC120VXPRS)
(E818, F818)
2 4 2 4
Hood, Seat, and Side Covers Replacement 0100 YRM 1243
10
