Table 15. Proc_Cal_013: Aux 3 Dir B Valve Output Threshold (Continued)
2. JOYSTICK
1. TILT BACK 2. AUX 1
DIRECTION A ↑
DIRECTION B ↓
3. LIFT ↓
4. ↑ LOWER
5. AUX 2
DIRECTION A ↑
DIRECTION B ↓
6. TILT FORWARD
7. SEAT ARMREST
Action 3: SLOWLY Activate (Feather) Aux 3 Dir B Control.....
NOTE: Optional for initial manufacture: Use the same pressure setting for both Dir A and Dir B of this function to
provide uniform flow outputs.
Action 4: Until the pressure is just above the standby pressure (as the needle moves on an analog gage). Note
that the pressure reading may oscillate. Hold control steady and.....
Action 5: WATCH for Attachment Movement. When it first starts to move slowly, HOLD control steady and.....
Press * One Time while holding the control.
Action 6: STOP activating the Aux 3 Dir B Control. LOOK at the display.
Go to the Calibration Step below that matches your display.
If You See..... Result out of range
Repeat Calibration
Press * One Time
You Will See: Aux 3 Valve Output
Dir B
Press * at Creep
Return to Action 3.
Pressure Method: Perform Actions 3, 4, and 6 again.
Visual Method: Perform Actions 3, 5, and 6 again.
If You See..... Calibrations
Aux 3 Valve Output Dir B
You May Quit and Save.....
Perform Proc_Cal_003: Save and Exit.
8000 YRM 1134 Proc_Cal_013: Aux 3 Dir B Valve Output Threshold
Confidential/Proprietary - Do Not Copy or Duplicate 39
To Next Page
