Yale HSA3400 User Manual

3
Contents
Contents
1 Location planning 4-5
2 Insert the batteries 6-7
3 Program the siren and keypad 8-9
4 Mounting the siren and keypad 10
5 Programming and mounting detectors 11
6 Using the system 13
Installing and using accessories 14
Changing the batteries 16
Specifications 18
Trouble shooting 19
Key points Back cover
Recommended installation sequence
We recommend you follow the easy start
sequence, headings numbered 1-6.
Subsequent sections provide:
• Use of additional accessories including keyfob
remote control, smoke detector and help
button.
Carton contents
1 x External siren
1 x Keypad remote control
2 x Passive infrared (PIR) detectors
2 x Door/Window contacts
2 x Door/Window contact magnets
4 x 1.5V AAA alkaline cells
6 x 1.5V AA alkaline cells
3 x 1.5V AAA alkaline cells
4 x 1.5V D alkaline cells
2 x large adhesive pads
2 x small adhesive pads
4 x small wall plugs
12 x medium wall plugs
4 x large wall plugs
4 x 4mm x 30mm cross head fixing screws
12 x 3.5mm x 16mm cross head fixing screws
4 x 3mm x 12mm cross head fixing screws
2 x window stickers
HSA3020 Passive infra-red (PIR) detector
HSA3030 3 x Passive infra-red (PIR) detectors
HSA3010 Door/window contact
HSA3090 Multiple door/window contact switches
HSA3060 Remote control (keyfob)
HSA3080 Remote keypad
HSA3045 Help button
HSA3070 Smoke detector
HSA3050 External siren
Accessories available
www.ukpanels.com

Yale HSA3400 Specifications

General

Brand	Yale
Model	HSA3400
Category	Security System
Language	English
