PIR movement detectors
Remove the fixing screw and cover assembly
and insert the three AA batteries as shown.
•The light steadily flashes for 30 seconds while
components initialise.
6
Unpack all the parts on a table top
The easiest way to get to know the system and get it up and running quickly is to get
all the devices and accessories programmed on a table top before locating and mounting them.
2
Siren
WARNING
The siren is very loud, be prepared! Take care
not to activate the siren tamper switch
unnecessarily.
1 Remove the cover by unscrewing the single
screw located at the bottom.
2 Remove the covers of the two internal
compartments.
3 Insert the four D batteries as shown.
There is a slight pause while the unit initialises.
The siren will then beep and the LEDs flash.
Tamper
switch
Jumper switch
Learn/Test button
Tamper
switch
Fixing holes
x 4
Jumper
switches
