cylinders
Illustration Description Model Number Number of Pins
Best
®
Keyway Cylinder. Available keyed
random, master keyed or uncombinated.
Specify keyway A, B, C, D, E, F, G, H, J,
K, L or M.
A600 6 or 7
Schlage
®
C Keyway.
Available 0-bitted or
keyed random.
2802
6
Sargent
®
LA Keyway.
Available 0-bitted or
keyed random.
3802
6
The 2802 and 3802 cylinders require an adapter sleeve
(P/N 14-5407-9101-999) and a cylinder sleeve (P/N 14-5305-9078-999) to fit the inTouch™ lockset.
other manufacturer keyway cylinders
levers accepting other manufacturers' interchangeable core cylinders
Description Prefix Ordering Example
SFIC
(accepts all Small Format
Interchangeable Cores)
6- or 7-pin.
B
(i.e. B-AU)
B-AU-E5361LN x 626
stand-alone touchpad access lock
7
Model No. Front “W” Front Width Backset Latch Diameter
380N Universal 1" (25mm) 2-3/8" (60mm) 7/8" (22mm)
380AN (standard) Universal 1-1/8" (29mm) 2-3/4" (70mm) 7/8" (22mm)
380CN Universal 1" (25mm) 2-3/4" (70mm) 7/8" (22mm)
Notes:
• 2-3/4" backset latches have a 7/8" diameter with a 1/8" sleeve (P/N 14-0378-9001) to
accommodate 1" door preps.
• All latches have universal fronts to fit both flat and beveled doors. When ordering latchbolts,
specify Model No. x Finish (e.g., 380N x 626)
deadlocking latchbolts
attaching screws
For all latchbolts
#8-8-32 x 3/4" (19mm) Phillips flat head combination
wood and machine screws.
Brass - P/N 81-2022-0416*
Bronze - P/N 81-2032-0416*
*specify finish required
latchbolts
