strikes
Yale
®
inTouch™ Locksets are available with a variety of strike options. All strikes are located on the same vertical
and horizontal center lines as the latchbolt. Some strikes are available in a variety of lip lengths to accommodate
varying thickness of doors and frames. To determine the proper length of the lip, measure from the center line of the
strike to the edge of the jamb and add 1/4" (6mm). All strikes are reversible.
Model No. 497 ANSI Strike (Standard)
For door and frames with ANSI/BHMA
A156.115 preparations. 1-1/4" supplied
standard. 1-1/8", 1-1/2", and 1-3/4" lip
lengths available by special order.
Model No. 371 Strike (Optional)
1-1/4" curved lip supplied standard. 1",
1-1/2", 1-3/4", and 2" curved lip lengths
available by special order. Wrought strike box
supplied.
Model No. 70S Full Lip Strike (Optional)
With full lip anti-rattle tab. Wrought strike box
supplied.
Model No. 71S Full Lip Strike (Optional)
1/4" radius. Similar in dimensions and
function to the 70S Strike but with radius
corners for easy mortising by power tools.
Anti-rattle tab. Wrought strike box supplied.
Model No. 202 Strike Box for ANSI Strike (Optional)
Specify 497 x 202
attaching screws
For Model Nos. 371, 70S, and 71S
#8-8-32 x 3/4" (19mm) Phillips flat head combination
wood and machine screws.
P/N 81-2012-0416
For Model No. 497
#12-12-24 x 1" Phillips flat head combination wood and
machine screws.
P/N 81-2012-0620
NOTE: When ordering strike or attaching screws individually, specify the finish required; i.e. 497 x 202 x 626; 81-2012-0620 x 626.
