Yale MORTISE 8800 SERIES - Page 12

August 2004
8808/8808-2
Page 12
8800 Series Parts & Service Manual
1 50-8800-2023 Strike, Curved Lip 1
2 50-8805-X019 Armor Front 1
3 50-8800-0010 Reversible Latchbolt Assembly 1
7 50-8899-0007 Guard Lever 1
8 50-8899-0008 Guard Lever Spring 1
9 50-8800-0003 Case Assembly 1
12 50-8899-0011 Cylinder Latch Lever 1
15 50-8899-0014 Spacer (Classroom) 1
20 50-8800-1015 Classroom Hub 1
22 50-8899-0017 Classroom Spring 1
28 50-8899-0023 Cylinder Retainer Assembly 1
31 50-8899-0029 Machine Screw (8-32 x 5/16) 4
32 50-8800-1008 Cover 1
34 50-8899-0031 Toggle Spring 1
36 50-8899-0033 Fire Stop Assembly 1
37 50-8899-0034 Spring Cartridge Assembly 1
38 50-8800-1005 Cap Hub 1
39 50-8800-1011 Spacer, Hub 1
40 50-8800-1004 Case Hub 1
42 50-8899-0036 Locking Piece Assembly 1
46 50-8899-0039 Guardbolt Spring 1
47 50-8899-0040 Spring Guide 1
48 50-8800-1016 Guardbolt Guide 1
49 50-8800-7014 Guardbolt 1
50 81-00X2-0404 Armor Front Screw 2
51 50-8800-1034 Knob Hub 2
52 50-4601-1005 Knob Hub Spacer 1
53 50-8899-0059 Latch Lever 1
54 50-8899-0061 Latch Lever Spring 1
55 50-8899-0060 Spacer Stop 1
56 50-8800-1031 SL Hub Spacer 1
ITEM PART NUMBER DESCRIPTION QUANTITY
