O1X
5
REF NO.
PART NO. DESCRIPTION REMARKS
QTY
*
: New Parts RANK: Japan only
RANK
* PN2 CIRCUIT BOARD ASSEMBLY (WA97830)
10 Circuit Board PN (PN1+PN2) (WA21740)
20 Push Button Black MR1B LENS EQ(LOW,LOW-MID,HIGH-MID, 9 01
HIGH),PAN,SEND,DYNAMICS,
GROUP,EFFECT
30 Push Button Dark Gray MR1G LENS AUTO R/W,SOLO,REC RDY, 6 01
SCENE,UTILITY,MONITOR A/B
40 Push Button White MR1LG LENS
AUTO EDIT,REMOTE,INTERNAL
901
SEL-CHANNEL,AUDIO,INST,
MIDI,BUS/AUX,OTHER
50 Push Button Black RTG1BX2 PAGE SHIFT
60 Push Button Gray RTG1LGX2 DISPLAY(Up,Down) 2
WA965000
--
V6776500
V6776800
V8600100
WA262300
WA263600
PN2シートAssy
PNシート集成
プッシュボタン(MR)
プッシュボタン(MR)
プッシュボタン(MR)
プッシュボタン(MR)
プッシュボタン(MR)
REF NO.
PART NO. DESCRIPTION REMARKS
QTY
*
: New Parts RANK: Japan only
RANK
* PN1 CIRCUIT BOARD ASSEMBLY 01X (WA97830)
10 Circuit Board PN (PN1+PN2) (WA21740)
60 Push Button Gray RTG1LGX2 Cursor(Left,Up,Down,Right 6
BANK(Left,Right)
70 Function Button Black F1B SHIFT,EDIT,UNDO,LOOP,SAVE 5 03
80 Function Button Dark Gray F1DG FLIP,F1-8,WRITE,MARKER, 13 01
ZOOM,SCRUB
* 90 Button White W_PLAY Play
* 91 Button White W_REC Record
* 92 Button White W_STOP Stop
* 93 Button White W_FF Fast-forward
* 94 Button White W_REW Rewind
WA964900
--
WA263600
V2646500
V7041300
WA656000
WA656100
WA656200
WA656300
WB174500
PN1シートAssy
PNシート集成
プッシュボタン(MR)
ファンクションボタン
ファンクションボタン
ボタン(LL)印刷品
ボタン(LL)印刷品
ボタン(LL)印刷品
ボタン(LL)印刷品
ボタン(LL)印刷品
● PN1 CIRCUIT BOARD ASSEMBLY (PN1シートAssy)
● PN2 CIRCUIT BOARD ASSEMBLY (PN2シートAssy)
部品名
部品名
