O1X
■ Others
Supplied Accessories Power Adaptor (PA-300), Owner's Manual set, CD-ROM x 2, mLAN (IEEE 1394) cable
Power Consumption 21 W
Dimensions 453(W) x 391(D) x 116(H) mm (including channel knobs' height)
Weight 6.2 kg
Operating free-air temperature range 10 - 35°C
■ Control
Analog Section Input Gain LINE/MIC Gain Knob 1 – 8 (+4 dB – -46 dB)
Monitor Volume MONITOR/PHONES Knob
Phantom Switch PHANTOM (+48 V) ON-OFF (rear panel)
Power Switch STANDBY/ON switch (rear panel)
Faders Faders 1 – 8, STEREO Fader
60 mm motorized, 0 – -132 – -∞ dB
Knobs/Dial Channel knobs 1 – 8 (Data Entry)
Rotary Encoder Dial (Song Position)
Panel Switches MODE INTERNAL, REMOTE, SCENE, UTILITY [BACK UP], MONITOR
PAGE SELECTED CHANNEL [LIBRARY], EQ-LOW, EQ-LOW-MID, EQ-HIGH-MID, EQ-HIGH, PAN [CH PARAM],
SEND [INST], DYNAMICS [PLUG-IN], GROUP, EFFECT
MIXER/LAYER AUDIO/1–8, INST/9–16(mLAN), MIDI/17–24(mLAN), BUS-AUX/MASTER, OTHER
FUNCTION F1 [TRACK], F2 [MIXER], F3 [LIST], F4 [CLOSE], F5, F6, F7, F8
DISPLAY UP, DOWN, DISPLAY SHIFT, NAME/VALUE [METER]
BANK < , >
CHANNEL SEL 1 – 8, STEREO SEL, ON 1 – 8, SOLO, REC RDY, AUTO EDIT, AUTO R/W
TRANSPORT REWIND, FORWARD, STOP, PLAY, RECORD, LOOP, MARKER, MARKER-WRITE
CURSOR UP, DOWN, LEFT, RIGHT, ZOOM
Others EDIT, UNDO, SAVE, FLIP, SHIFT, SCRUB
Display LCD 55 x 2 character LCD (backlit)
■ Input/Output Specifications
Analog Input Connector
Input level
Nominal Max. before clip Actual Load Impedance
MIC/LINE INPUT 1, 2 XLR type, Balanced, -46 dB – +4 dB +18 dB 3 kΩ
+48 V +3 V/-3 V Phantom
MIC/LINE INPUT 3 - 8 TRS Phone, Balanced -46 dB – +4 dB +18 dB 3 kΩ
MIC/LINE INPUT Hi-Z Phone, Unbalanced -46 dB – +4 dB +18 dB 500 kΩ
Analog Output Connector
Output level
Nominal Max. before clip Actual Source Impedance
MONITOR OUT (L, R) Phone, Unbalanced -10 dBV +4 dBV 10 kΩ
STEREO/AUX OUT (L, R) Phone, Unbalanced -10 dBV +4 dBV 10 kΩ
PHONES TRS Phone, Unbalanced 100 mW + 100 mW 8 – 40 Ω
(40 Ω load)
Digital Input/Output Connector Format Recommended output level Other details
DIGITAL IN, OUT RCA PIN
IEC-60958 Consumer use 0.5 Vpp/75 Ω SRC On/Off is possible on the
input side, Dither On/Off
possible on the output side
MIDI IN, OUT A/B DIN (5 pin) MIDI - -
mLAN 1/2 IEEE 1394 (6 pin) IEEE 1394/FireWire - -
FOOT SWITCH 1/2 PHONE
