78
O1X
(4) Item description and error message
None
(5) Check point when judged as NG
The devices that can be diagnosed by this check are as follows.
Circuit board Device name Function
DM DSP7 (IC210) MIXER
AN CS5351 (IC116, IC117, IC216, IC217) ADC
AN AK4382 (IC301, IC302) DAC
4.18 AD58 to DA14 through function check .....
(18) AD58DA14 (48k)
(1) Outline
The input signal of AD5-8 is output to DA1-4 and the circuit of
the analog signal system is checked. Specifically the following
signal passages are checked.
MIC/LINE INPUT5 ->DM circuit board ->MONITOR OUT L
MIC/LINE INPUT6 ->DM circuit board ->MONITOR OUT R
MIC/LINE INPUT7 ->DM circuit board ->STEREO/AUX OUT L
MIC/LINE INPUT8 ->DM circuit board ->STEREO/AUX OUT R
MIC/LINE INPUT5 ->DM circuit board ->PHONES L
MIC/LINE INPUT6 ->DM circuit board ->PHONES R
MIC/LINE INPUT5 ->DM circuit board ->DIGITAL STEREO
OUT L
MIC/LINE INPUT6 ->DM circuit board ->DIGITAL STEREO
OUT R
The word clock of this unit is Internal 48KHz.
(2) Execution method in the normal state
When proper operation is confirmed, press [KNOB-8]. The screen
returns to the execution select screen and "O" is displayed in the
check item space.
18:AD58DA14
NG OK
(3) Execution method in the faulty state
If checking is terminated before the end due to a faulty condition,
press [KNOB-7]. The screen returns to the execution select
screen and "X" is displayed in the check item space.
(4) Item description and error message
None
(5) Check point when judged as NG
The devices that can be diagnosed by this check are as follows.
Circuit board Device name Function
DM DSP7 (IC210) MIXER
AN CS5351 (IC116, IC117, IC216, IC217) ADC
AN AK4382 (IC301, IC302) DAC
4.20 AD58 to DA14 through function check .....
(20) AD58DA14 (96k)
(1) Outline
The input signal of AD5-8 is output to DA1-4 and the circuit of
the analog signal system is checked. Specifically, the following
signal passages are checked.
MIC/LINE INPUT5 ->DM circuit board ->MONITOR OUT L
MIC/LINE INPUT6 ->DM circuit board ->MONITOR OUT R
MIC/LINE INPUT7 ->DM circuit board ->STEREO/AUX OUT L
MIC/LINE INPUT8 ->DM circuit board ->STEREO/AUX OUT R
MIC/LINE INPUT5 ->DM circuit board ->PHONES L
MIC/LINE INPUT6 ->DM circuit board ->PHONES R
MIC/LINE INPUT5 ->DM circuit board ->DIGITAL STEREO
OUT L
4.19 AD14 to DA14 through function check .....
(19) AD14DA14 (96k)
(1) Outline
The input signal of AD1-4 is output to DA1-4 and the circuit of
the analog signal system is checked. Specifically the following
signal passages are checked.
MIC/LINE INPUT1 ->DM circuit board ->MONITOR OUT L
MIC/LINE INPUT2 ->DM circuit board ->MONITOR OUT R
MIC/LINE INPUT3 ->DM circuit board ->STEREO/AUX OUT L
MIC/LINE INPUT4 ->DM circuit board ->STEREO/AUX OUT R
MIC/LINE INPUT1 ->DM circuit board ->PHONES L
MIC/LINE INPUT2 ->DM circuit board ->PHONES R
MIC/LINE INPUT1 ->DM circuit board ->DIGITAL STEREO
OUT L
MIC/LINE INPUT2 ->DM circuit board ->DIGITAL STEREO
OUT R
The word clock of this unit is Internal 96KHz.
(2) Execution method in the normal state
When proper operation is confirmed, press [KNOB-8]. The
screen returns to the execution select screen and "O" is displayed
in the check item space.
19:AD14DA14 (96k)
NG OK
(3) Execution method in the faulty state
If checking is terminated before the end due to a faulty condition,
press [KNOB-7]. The screen returns to the execution select
screen and "X" is displayed in the check item space.
(4) Item description and error message
None
(5) Check point when judged as NG
The devices that can be diagnosed by this check are as follows.
Circuit board Device name Function
DM DSP7 (IC210) MIXER
AN CS5351 (IC116, IC117, IC216, IC217) ADC
AN AK4382 (IC301, IC302) DAC
