Yamaha 100A - Inspecting and Replacing Anode

4-24
GB
601033
5) With the outboard motor in an verti-
cal position, using a flexible or pres-
surized filling device, inject outboard
motor hypoid gear oil (SAE 90) into
the oil drain plug hole.
6) When oil begins to flow out of the oil
level plug hole, insert and tighten the
oil level plug.
7) Screw in the oil drain plug.
Gear oil capacity:
Refer to SPECIFICATIONS, Page 4-1.
EML24010
INSPECTING AND REPLACING
ANODE
Yamaha outboard motor is protected
from corrosion by a sacrificial anode.
Check the anode periodically. Remove the
scales from surfaces of the anode.
For the replacement of the anode, consult
a Yamaha dealer.
cC
Do not paint the anode, for this would
render it ineffective.
603024
405016
