Yamaha 100A - Tilt Support Lever

2-15
GB
802031
TRIP TIME BATT
Km/h
knot
mph
km
mile
SPEED
YAMAHA
set
mode
q
w
802026
TRIP TIME BATT
Km/h
knot
mph
km
mile
SPEED
qw
EMU00145
Warning indicator
8 Fuel warning
If the fuel level decreases to one segment
the fuel level warning segment 1 begins
blinking.
8 Low battery voltage warning
If battery voltage drops, the display 2 will
be automatically turned on and it begins
blinking.
cC
Do not continue to operate the engine if a
warning device has activated. Refer to
the TROUBLESHOOTING section in this
manual. Consult a Yamaha dealer if the
problem cannot be located and corrected.
403033
EMD60010
TILT SUPPORT LEVER
To keep the outboard motor in the tilted-
up position, lock the tilt support lever to
the clamp bracket.
64C-9-76 (E,F,ES) 2 4/25/0 2:53 PM Page 52
