MAIN COMPONENTS
TRIPTRIP TIMETIME BATTBATT
Km/hKm/h
knotknot
mphmph
kmkm
milemile
SPEEDSPEED
YAMAHAYAMAHA
setset
modemode
!5
!6
!8
!7
q
w
e
r
t
y
u
i
o
!0
!1
!2
!3
!4
!1
V150
1 Power trim and tilt switch
2 Flushing device
3 Tilt support lever
4 Anti-cavitation plate
5 Trim tab (Anode)
* 6 Propeller
7 Cooling water inlet
8 Anode
9 Clamp bracket
0 Power trim and tilt unit
q Cowling lock lever
w Choke knob
e Top cowling
r Cooling water pilot hole
* t Remote control box (Side mount type)
* y Digital tachometer
* u Digital speedmeter
* i Remote oil tank
* May not be exactly as shown; also may not
be included as standard equipment on all
models.
