2-7
E
UP
DN
701034**
UP
DN
DOWN
UP
702042
EMU01112
Power Trim/Tilt Switches
The power trim/tilt adjusts the motor
angle in relation to the transom. The
power trim/tilt switch is located on the
remote control lever grip. Individual-
engine switches are also on the control
cover. Pushing the switch “UP” trims the
motor up, then tilts the motor up. Press-
ing the switch “DN” tilts the motor down
and trims the motor down. When the
switch button is released, the motor will
stop in its current position.
NOTE:
8 On the dual engine control, the switch
on the remote control grip controls both
engines at the same time.
8 Refer to the sections “Adjusting Trim
Angle” and “Tilting Up/Down” in Chap-
ter 3 for instructions on usage.
