Yamaha 2011 YZ250 User Manual

4-21
CLUTCH
CLUTCH
REMOVING THE CLUTCH
Order Part name Q'ty Remarks
Drain the transmission oil.
Refer to "CHANGING THE TRANSMISSION
OIL" section in the CHAPTER 3.
Bolt (brake pedal) Shift the brake pedal downward.
Rotor and stator Refer to "CDI MAGNETO" section.
Clutch cable Disconnect at engine side.
1 Clutch cover 1
2 Bolt (clutch spring) 6
3 Clutch spring 6
4 Pressure plate 1
5 Friction plate 8
6 Clutch plate 7
10 Nm (1.0 m kg, 7.2 ft lb)
10 Nm (1.0 m kg, 7.2 ft lb)

Yamaha 2011 YZ250 Specifications

General

Engine Type	249cc liquid-cooled 2-stroke; reed-valve inducted
Bore x Stroke	66.4mm x 72.0mm
Ignition	CDI
Final Drive	Chain
Brakes / Front	Hydraulic single disc brake, 250mm
Brakes / Rear	Hydraulic single disc brake, 245mm
Tires / Front	80/100-21
Tires / Rear	110/90-19
Seat Height	39.1 in
Wheelbase	58.3 in
Ground Clearance	14.2 in
Fuel Capacity	2.1 gal
Transmission	5-speed
Suspension / Front	11.8-in travel
Suspension / Rear	12.4-in travel
Wet Weight	227 lb
Compression Ratio	8.9:1 - 10.6:1
